Product Overview & Technical Innovation
The Printer RFID QR Code Scanner is an advanced, all-in-one ticketing solution that integrates three essential functions—high-speed thermal printing, RFID encoding, and QR code scanning—into a single compact device.
Built with a proprietary high-performance direct-thermal engine, it delivers printing speeds up to twice as fast as traditional models. At the same time, its high-frequency RFID module enables precise chip encoding, while the multi-spectrum imaging scanner ensures rapid and reliable QR code verification.
A unified processing architecture coordinates all functions in real time, eliminating transmission delays and enabling a seamless workflow ideal for modern Park Ticketing environments. Additionally, its modular component design supports independent replacement of printing, encoding, or scanning modules, greatly minimizing maintenance downtime and ensuring uninterrupted operation for large-scale park systems.
Implementation Scenarios
1. On-Demand Ticket Issuance
Instantly prints and encodes multi-format tickets featuring RFID access credentials and QR codes for fast verification and redemption.
2. Membership Card Production
Produces customized membership cards with securely encoded privileges and QR code backups for enhanced user flexibility.
3. Centralized Service Centers
Acts as a comprehensive service terminal for ticket upgrades, replacements, special-access issuance, and other support operations.
Printing Technology： Direct-thermal 4-inch/sec printing with 203 DPI resolution and automatic cutter
RFID Encoding： HF 13.56MHz (MIFARE Classic/DESFire) with 50mm read/write distance
Scanning Performance： 2MP CMOS sensor reads QR/DM/Barcode at 5–45cm with 0.3s recognition
Media Handling： 80mm paper roll capacity with paper-out sensor and jam detection system
Connectivity： Dual Ethernet (TCP/IP), USB 3.0, Rs-232, and optional Wi-Fi 6 module
- Processing Unit： Quad-core 1.6GHz processor with 2GB RAM running Linux OS
Power Supply： 24V DC with wide voltage input (100–240V) and surge protection
Operating Environment： 0°C to 45°C with 20–80% humidity tolerance for indoor/outdoor use
Physical Design： Compact 280×180×150mm steel enclosure with VESA mount compatibility
Integration API： RESTful JSON API for seamless Access Control system integration
